Hi!

How a Missing Workflow Name Breaks DevUI (and How to Fix It)

When working with Microsoft Agent Framework and DevUI, I ran into a subtle but very frustrating issue: everything compiled, but DevUI failed at runtime.

No workflows visible.
No clear hint in the UI.
And a runtime exception that didn’t immediately point to the real problem.

Let’s break it down or catch the video where I explain everything in 8 minutes.

The Problem: DevUI Requires a Workflow Name

DevUI relies on workflow metadata to visualize and execute workflows.
One of those required pieces of metadata is the workflow name.

The problem?
Some workflow builders—like Handoff workflows—don’t expose a way to explicitly set the name.

So you end up with a workflow that exists, but has an empty name.

The Runtime Error

Here’s the exception DevUI throws when this happens:

System.InvalidOperationException
Message=The workflow factory returned workflow with name '', but the expected name is 'HandOffWorkflow'.
Source=Microsoft.Agents.AI.Hosting

This happens during DevUI startup, when it tries to map and register workflows.

screenshot of the ide triggering the error

The Code That Triggers the Error

This workflow registration looks perfectly fine:

builder.AddWorkflow("HandOffWorkflow", (sp, key) =>
{
    var chatClient = sp.GetRequiredService<IChatClient>();
    var searchFunctions = sp.GetRequiredService<SearchFunctions>();
    var researchAgent = sp.GetRequiredKeyedService<AIAgent>("ResearchAgent");
    var writerAgent = sp.GetRequiredKeyedService<AIAgent>("WriterAgent");

    var technicalAgent = chatClient.CreateAIAgent(
        name: "TechnicalAgent",
        instructions: @"You are a technical specialist...",
        tools: [AIFunctionFactory.Create(searchFunctions.SearchAsync)]);

    var businessAgent = chatClient.CreateAIAgent(
        name: "BusinessAgent",
        instructions: @"You are a business specialist...",
        tools: [AIFunctionFactory.Create(searchFunctions.SearchAsync)]);

    var creativeAgent = chatClient.CreateAIAgent(
        name: "CreativeAgent",
        instructions: @"You are a creative specialist...",
        tools: [AIFunctionFactory.Create(searchFunctions.SearchAsync)]);

    var routerAgent = chatClient.CreateAIAgent(
        name: "RouterAgent",
        instructions: @"You are a routing coordinator...");

    var workflow = AgentWorkflowBuilder.CreateHandoffBuilderWith(routerAgent)
        .WithHandoff(routerAgent, technicalAgent)
        .WithHandoff(routerAgent, businessAgent)
        .WithHandoff(routerAgent, creativeAgent)
        .WithHandoff(routerAgent, researchAgent)
        .WithHandoff(routerAgent, writerAgent)
        .Build();

    return workflow;
});

But the workflow returned by Build() has no name, even though the registration expects "HandOffWorkflow".

Why This Breaks DevUI

AddWorkflow("HandOffWorkflow", …) expects the workflow to report the same name
DevUI queries registered workflows and validates names
An empty name causes:
- Workflow mapping failure
- DevUI startup exception
- No workflows visible in the UI

The Fix: Assign the Name After Build

The simplest fix is to set the workflow name manually after building it.

var workflow = AgentWorkflowBuilder.CreateHandoffBuilderWith(routerAgent)
    .WithHandoff(routerAgent, technicalAgent)
    .WithHandoff(routerAgent, businessAgent)
    .WithHandoff(routerAgent, creativeAgent)
    .WithHandoff(routerAgent, researchAgent)
    .WithHandoff(routerAgent, writerAgent)
    .Build();

workflow.SetName("HandOffWorkflow");

return workflow;

This makes the workflow compatible with DevUI immediately.

The Trick: Setting a Readonly Property via Reflection

Since the Name property is readonly, we need a small extension that uses reflection.

Here’s the full extension class (about ~20 lines of real logic):

using Microsoft.Agents.AI.Workflows;
using System.Reflection;

namespace ChatApp20.Web.Extensions;

public static class WorkflowExtensions
{
    public static T SetName<T>(this T workflow, string name) where T : class
    {
        InvokeSetWorkflowName(workflow, name);
        return workflow;
    }

    private static void InvokeSetWorkflowName<T>(T workflow, string name) where T : class
    {
        var type = workflow.GetType();

        var nameProperty = type.GetProperty("Name", BindingFlags.Public | BindingFlags.Instance);

        if (nameProperty != null)
        {
            var backingField = type.GetField("<Name>k__BackingField",
                BindingFlags.NonPublic | BindingFlags.Instance);

            if (backingField != null)
            {
                backingField.SetValue(workflow, name);
            }
            else if (nameProperty.CanWrite)
            {
                nameProperty.SetValue(workflow, name);
            }
        }
    }
}

Result

✅ DevUI loads correctly
✅ Workflow appears in DevUI
✅ Runtime error gone
✅ No changes needed in Agent Framework itself

Final Thoughts

This is one of those “everything compiles but nothing works” problems.

If you’re using:

Microsoft Agent Framework
DevUI
Handoff or generated workflows

👉 Always make sure your workflows have a name.

If you have a cleaner solution—or if the framework adds native support for this later—let me know. I’d love to know more!

Happy coding!
